Mini Industrial 2-Port 10/100Base-TX to 100Base-FX Media Converter

Name: Mini Industrial 2Port 10100BaseTX to 100BaseFX Media Converter
Brand: E-link
Price: 1 USD

Buy cheap Mini Industrial 2-Port 10/100Base-TX to 100Base-FX Media Converter product

Brand Name : E-link

Model Number : The LNK-IMC1200

Certification : CE, RoHS, FCC

Place of Origin : China

MOQ : 1pair

Price : negotiation

Payment Terms : L/C, T/T, Western Union, MoneyGram, Paypal

Supply Ability : 1000pcs/month

Delivery Time : 5-12 working days

Packaging Details : Media Converter Standard Export Package

Key Word : Mini Industrial Media Converter

Input Power : 12~48VDC

Weight : 0.25Kg

Dimensions (WxDxH） : 95 x 70 x 30 mm

Operating Temperature : -40°C to 75°C

Mounting Options : DIN-Rail / Wall-mount

Contact Now

Mini Industrial Media Converter Advantages

► 2-Port 10/100BASE-T RJ45 with auto MDI/MDI-X function

► 1-Port 100Base-FX SC

► Supports Full/Half-duplex, Auto-negotiation

► IEEE 802.3az Energy Efficient Ethernet (EEE)

► 12~48VDC Terminal Block Power Input

Technical Indexes

Interface
Connector:	2 x RJ45
Optical Port:	1 x SC 100Base-FX
Environmental
Operating Temperature:	-40°C to 75°C (-40°F to 167°F)
Storage Temperature:	-40°C to 85°C (-40°F to 185°F)
Relative Humidity:	5% to 95% non-condensing
MTBF	> 200,000 hrs

Overview

The LNK-IMC1200 Series provides media conversion between 2-Port 10/100BASE-T and 1-Port 100BASE-FX Fiber. It’s a

hardened product with wide operating temperature range from -40°C to 75°C, and ruggedized aluminum housing.

Mini Industrial 2-Port 10/100Base-TX to 100Base-FX Media Converter

Ordering Information

Model	Description
LNK-IMC1200	Mini Industrial Media Converter, 1-port 100BASE SC + 2-port 10/100BASE-T, SC Fiber Port, Multimode, 1310nm, 2km
LNK-IMC1200-20	Mini Industrial Media Converter, 1-port 100BASE SC + 2-port 10/100BASE-T, SC Fiber Port, Single Mode, 1310nm, 20km
LNK-IMC1200-S20	Mini Industrial Media Converter, 1-port 100BASE SC + 2-port 10/100BASE-T, SC Fiber Port, Single Mode, Single Fiber, 1310/1550nm, 20km
Mounting Options	► Default DIN-Rail Bracket installed; Wall Mount Bracket is included.
Power Options	► 24W/1A 24VDC Power Supply. Open Wire for Terminal Block
Power Options	► Power Supply is to be purchased separately.

Product Tags:

100Base-FX Media Converter

2-Port Media Converter

Mini Industrial Media Converter

Mini Industrial 2-Port 10/100Base-TX to 100Base-FX Media Converter Images
